747PD - Honeywell Home Hardwired Alarm Siren (Indoor, Low-Current Draw, 2-Tone, 105dB)

747PD - Honeywell Home Hardwired Alarm Siren (Indoor, Low-Current Draw, 2-Tone, 105dB)
747PD - Honeywell Home Hardwired Alarm Siren (Indoor, Low-Current Draw, 2-Tone, 105dB)
Item# 747PD
List Price: $46.55
Your Price: $31.04
Availability: In Stock
QTY:

Honeywell 747PD Product Description:


The Honeywell 747PD is a indoor, piezo dynamic series, 105dB, hardwired alarm siren. The 747PD sirens produces traditional "speaker" sound while drawing 1/4 the current of typical sirens. This allows multiple devices to be installed on the same alarm panel without the need for additional hardware, costs and labor.

The 747PD siren features a sleek, lightweight design, an easy-to-wire terminal block and a hinged case cover. The 747PD siren is globally compliant and UL approved and ideal for residential application.

Product Features:

  • Low current draw lets you add additional sirens in areas like basements, garages, hallways and more
  • Two tones to choose from: Steady and Warble
  • Lightweight ABS plastic case is less than half the weight of standard sirens
  • Enclosed PCB to protect components
  • Easy-to-wire terminal block eliminates the need to splice and crimp wire
  • Hinged case cover with elliptical mount holes provide installation convenience
  • Tampered versions available to provide an added level of protection and meet global requirements
  • Compatible with LYNX control panels
  • Large wiring channel provides plenty of room for wire
  • Backed by Honeywell's 2-year limited manufacturer's warranty

Honeywell 747PD Product Specifications:


  • Dimensions: 4.25"W x 4.25"H x 1.25"D
  • Color: White
  • Sound Output: 105dB @ 1 meter
  • Current draw: 120mA
  • Operation Voltage: 12VDC
  • Weight: 0.35 lbs

Honeywell 747PD Product Compatibility:


• Hardwired Control Panels (works universally across brands)
