Product Features:

• 2.4MP Video Resolution - Delivers clear, detailed front-door video for everyday monitoring.
• Battery-Powered Installation - Allows flexible placement without relying on existing doorbell wiring.
• Rechargeable, Replaceable Battery - Designed for convenient charging and ongoing service.
• Dual-Band Wi-Fi - Supports both 2.4 GHz and 5 GHz Wi-Fi connectivity.
• Advanced Video Analytics - Helps detect and classify important activity for more meaningful alerts.
• Familiar Face Analytics - Can recognize familiar people when enabled with supported Alarm.com services.
• Package Detection - Helps identify package delivery activity at the door.
• Two-Way Audio - Enables users to see and speak with visitors remotely through Alarm.com.
• Wide Field of View - Provides broad coverage of the front-door area.
• Wireless Smart Chime Included - Comes with the ADC-W114C Wi-Fi Smart Chime for indoor audible notifications.
• Customizable Chime Tones - Supports selectable sounds for compatible doorbell presses and alerts.
• Adjustable Chime Volume - Lets users tailor audio levels to the installation environment.
• Configurable Chime Rules - Supports customizable rules for when and how the chime responds.
• Scheduled Alerts - Chime behavior can be configured through the Alarm.com platform.
• Video Event Audio Alerts - Provides audible notifications for supported camera and video events.
• Simple Plug-In Chime Installation - The ADC-W114C plugs directly into a standard electrical outlet.
• No Traditional Mechanical Chime Required - Provides a convenient wireless alternative to a conventional wired chime.
• Alarm.com Integration - Supports remote viewing, notifications, video events, and compatible security features through the Alarm.com platform.
• Remote Management - Supported settings can be managed and troubleshot through Alarm.com.

ADC-VDB780B Video Doorbell

• Dimensions (W x L x D): 2.5 x 5.3 x 1.2" (64 x 134 x 30 mm); mounting bracket adds 0.2" (6 mm) to depth
• Recording compression: H.264
• Ingress protection: IP66
• Max resolution: 1920x1080
• Image sensor: 2.12 MP - 1080p, Sony IMX323 ABRcontrol support and MJPEG
• Lens/angle of view: 160° horizontal, 90° vertical, 175° diagonal
• Low-light sensitivity: 0.5 lux with IR LED off
• IR range: Up to 15 feet (5 meters)
• Image adjustments: Flip, brightness, contrast, saturation, sharpness, exposure
• Wi-Fi connectivity: 802.11 b/g/n, 2.4 GHz
• Operating and storage temperature: -4°F to 122°F (-20°C to 50°C)
• Operating humidity: 20% to 95% condensing RH
• Motion sensor: Passive infrared sensor
• Battery pack capacity: 9540mAh nominal capacity
• Charging requirement: 5V/1.5A charger
• Charging time: Up to 7 hours
• Speaker: 1W, 8Ω speaker
• Microphone: Single, omni-directional, analog, >-40dBV/Pa

ADC-W115C Smart Chime and WiFi Access Point

• Dimensions with Antennas (H x W x D): 5.0 x 1.0 x 2.1" (12.7 x 13.0 x 5.4 cm)
• Dimensions without Antennas (H x W x D): 3.3 x 3.3 x 2.1" (8.5 x 8.5 x 5.4 cm)
• WiFi Connection: 802.11 b/g/n, 2.4 GHz
• WiFi Security: WPA2
• LED Indicators: 4
• Buttons: WPS, Reset
• Antennas: 2
• WiFi Chime: 1.5 W speaker, 77 dB
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Operating humidity: 10% to 90% condensing RH
• Motion sensor: Passive infrared sensor
• Battery pack capacity: 9540mAh nominal capacity
• Charging requirement: 5V/1.5A charger
• Charging time: Up to 7 hours
• Speaker: 1W, 8Ω speaker
• Microphone: Single, omni-directional, analog, >-40dBV/Pa

ADC-VDB781B Battery Video Doorbell:

• Data Sheet
• Installation Guide
• Charge Battery
• Wiring Guide
• Factory Reset to Default Settings

ADC-W114C Smart Chime:

• Data Sheet
• Installation Guide
• Default Settings
• LEDs Mean
• Create Automation Rules
• Configure Settings
• Ping to Verify Proper Communications
• DHCP Range Used

Included Accessories

• Alarm.com ADC-VDB781B Wireless Video Doorbell
• Alarm.com ADC-W114C Wireless Wi-Fi Smart Chime
• ADC Universal Battery Pack
• ADC-VDB781B wallplate (with pre-assembled set screw and wire terminal screws)
• 5° tilt wedge (optional)
• Security screw tool
• M3.5 wallplate mounting screws 20 mm length (x2)
• M3.5 drywall anchors 25 mm length (x2)
• Conical anchors for concrete installations (x2)
• M3 wedge mounting screws (x2)
• Wallplate rubber spacers (x2)
• USB-C charging cord
• Installation card with scannable QR code

Additional Accessories

• ADC-VACC-BAT-2LIB18650 - Accessory Battery Pack for Alarm.com Indoor/Outdoor Battery Camera
• ADC-VDBA-781B-WMK - VDB781B Wedge Mount Kit
