The Honeywell LCP300-LC Lyric Gateway Canada serves as the central hub for the Honeywell LCP500-LC Lyric Controller security system, lifestyle management, lights, locks, thermostats and more that are all controlled via integrated touchpads and wirelessly on smart devices. The LCP300-LC gateway hub is an IP (WiFi and Ethernet) and cellular enabled device, that installs quickly and easily. The LCP300-LC central hub is designed for the way Canadian consumers really live delivering a great connected home experience right out of the box.
You don't operate on a fixed schedule. Why should your home? Lyric is designed for how you really live, with a wireless connected platform that makes your home safer, smarter and more enjoyable. The Lyric Gateway puts your home at your fingertips, with with an economical, easy-to-use system from your everyday mobile device or a sleek, easy-to-use interface. The only limitation is your imagination. View live video, control security and home automation and more, whether you're at home, on the go or at your desk. Think you forgot to turn off your porch lights while watching a movie? Just check your iOS or Android™ device.
Product Height: 8.82 inches (22.4cm) Product Depth: 1.4 inches (3.6cm) Product Width: 6.97 inches (17.7cm) Product Weight: 2.2 pounds (1kg) Operating Temperature: 32° - 122°F (0°-50°C) User Interface: Capacitive touch interface with advanced voice guidance Lyric® Lock: Speaker, Microphone, Sounder with 85 dB intensity Connectors and Modules: Cellular module tray (end-user replaceable), Internal backup battery module (end-user replaceable) Built-in Technology: WiFi® (802.11 b/g/n); (2.4 GHz), Ethernet port (10/100), Z-Wave® Plus; Network Wide Inclusion supported, SiX™ Two-Way Wireless Technology, Honeywell 5800 Series wireless sensors Supported Technology: CDMA-1xRTT (800, 1900MHz); Plug-in Option, GSM-3G HSPA (850, 1900MHz); Plug-in Option Cellular: CDMA-1xRTT
(800, 1900MHz); Plug-in Option, GSM-3G HSPA
(850, 1900MHz); GSM: AT&T® and Rogers™, CDMA: Verizon® Sounds: 10 selectable chime sounds when a sensor is tripped, allowing for different sounds for any door/window (ex: a door opens or closes) Voice Announcement: Listen to system state, sensor state, and more (e.g., armed away or front door open) Users: 48 system users User Profiles: Installer, Master User, Standard User, Guest, Duress Wireless Keys: Honeywell SiX™ Two-Way Wireless and 5800-Series Wireless Keys, Supports up to eight wireless keys, each typically assigned to one user, Wireless key supports up to eight action keys Supported Devices: 64 wireless sensors, SiX™ Two-Way Wireless Sensors, 5800 Series sensors Common SiX Sensors: Sensor for doors and windows, Motion detector, Glassbreak detector, Smoke detector with one-go-all-go capabilities, Siren with audible and visual indications Keypads: Supports eight SiX Two-Way Wireless Keypads (Arm and Disarm, Status of System, Seek emergency response, sounds and voice announcements) Z-Wave® Support: 76 Z-Wave devices Common Solutions: 6 Z-Wave thermostats, 6 Z-Wave door locks, 4 Z-Wave garage doors, 60 light modules (light dimmers, appliance modules, window shades, blinds, water valves, sirens and/or strobes) WiFi Thermostats: 4 Lyric WiFi thermostats Remote Operation: Honeywell Total Connect® Remote Services application on iOS (iPhone® and iPad®), Android™ and Web Remote Operation Features: Manage users of the system, create/run or delete 100 smart scenes to combine states of discrete devices into one command, configure smart scenes to occur based on time/device/system trigger or on manual activation, set up and receive notifications based on activity at the site Local Control and Setup: Support for MyHome Gateway app (iOS and Android), Subscription-free option for users to control their system from anywhere at the premise, Up to eight devices Emergency Response: Dedicated emergency response button for users to request assistance from authorities Emergency Response Types: Fire, Police and Medical Emergency Alerts: A loud alarm or sound for; Break-ins when system is armed, potentially unsafe levels of smoke or carbon monoxide, fire or carbon monoxide and burglary event Cloud-Based Programming: Program and test using AlarmNet 360™ (from a smartphone, tablet or a web browser), schedule and deliver software or firmware updates to Lyric hardware over-the-air, monitor system usage and activity, remote diagnostics and troubleshooting, keep a record of system test results Local Programming: Use AlarmNet 360™ app to program, test and verify system operations, Update firmware and download template into the system at the site in the absence of connection to AlarmNet 360™ Power Requirements: Plug-in power supply, 110VAC mains to 9VDC with 2.7A output Backup Battery: 4-hour (1100mAh) included or optional 24-hour (3700mAh), Rechargeable NiMH cells rated at 7.2VDC
