WAVE2F - Honeywell Home Hardwired Alarm Siren (Indoor, Flush-Mount, 2-Tone, 106dB)
Honeywell WAVE2F Product Description:
The Honeywell WAVE2F is a indoor, 2-tone, 106db output, flush-mount, hardwired alarm siren. The WAVE2F has two-tones for sound pressures, steady and warbel.
The WAVE2F has a unique snap-open HINGED CASE DESIGN which is an industry first for sounders. The WAVE2F also has a terminal strip so no soldering or wire splicing is required. The case back is channelled for convenient wiring access and the patented case design fits a double gang recessed electrical box or wall plate. This unique design allows for easy installation without disassembly.
Product Features:
- Attractive new design fits single gang wall plate
- Lounder (106db) dual tone siren output
- Unique hinged case design - allows for installation without dis-assembly
- Terminal strip eliminates soldering and splicing
- Easy terminal block wire connections
- Channeled case back for convenient wiring access
- Mounts recessed
- Standard double gang box size
- Backed by Honeywell's 2-year limited manufacturer's warranty
Honeywell WAVE2F Product Documents:
• Data Sheet for Honeywell Hardwired Alarm Siren (WAVE2F)
• Installation Guide for Honeywell Hardwired Alarm Siren (WAVE2F)
Honeywell WAVE2F Product Specifications:
- Dimensions: 3.25"W x 4.25"H x 2.0"D (82.5mm W x 108mm H x 51mm D)
- Color: White
- Housing: ABS 94 VO Plastic, with hinged case cover
- Operating Temperature: 20°F to 175°F
- Current draw: 500mA Max. @ 12 VDC
- Sound pressure (steady): 106db @ 12 VDC, 1 meter
- Sound pressure (warbel): 106db @ 12 VDC, 1 meter (500mA Max)
- GND - Ground: 106db
- Mounting: Recessed (in Double-gang electrical box)
- Impedance: 8 ohms, 15W peak
- Connection: 3 position Terminal Block
- Agency Listing: UL1023, 985, and 464
Honeywell WAVE2F Product Compatibility:
• Hardwired Control Panels (works universally across brands)
• FA168C-GP
• FA1220C
• LYNX-CN
• VISTA-20PI
• VISTA-40EX
• 4110
• 4111XM
• 4140XM
• 4140XMPT
• FA1000C
• FA100C
• FA140C
• FA145C
• FA147C
• VIA-16
• VIA-30
• VIA-30P
• VISTA-20
• VISTA-20EX
• VISTA-20HW
• VISTA-20PUL
• FA162C
• FA168CPS
• FA148CP
• FA148CPSIA
• FA168CPS-CN
• FA148CP-CN
• FA168C
• FA168CPSSIA
• FA168C-CN
• FA150C
• FA160C
• 4110XMP
• FA110C
• 4110XM
• 4110DL
• 4120XM
• 4140XMP
• FA130CPSIA
• FA1340C
• FA120C
• FA1220CV
• FA130CP
• VISTA-15P
• VISTA-15PCN
• VISTA-15PSIA
• VISTA-20P
• VISTA-20PCN
• VISTA-20PS
• VISTA-20PSIA
• VISTA-20SE
• VISTA-20SECN
• VISTA-20SEUL
• VISTA-21IP
• VISTA-21IPSIA
• VISTA-40
• VISTA-48C
• VISTA-48LA
• VISTA-50EX
• VISTA-50P
• VIA-30PSE
• VISTA-10P
• VISTA-10PSIA
• FA1200C
